rbo-136
RBO-136 Rotary Rack Oven
The RBO-136 is an ultra-high-capacity rotary rack oven built by RotoBake in New Delhi for integrated industrial bread production lines. It holds 136 trays (13" × 18" each) across a 45,016 sq. in. baking area, baking approximately 343 loaves per 25-minute cycle, or up to 100 kg/hr of cookies. The oven operates across a ambient to 350°C temperature range and runs on diesel or gas — diesel consumption is roughly 5 L/hr, gas roughly 4.5 kg/hr. Built in food-grade steel, the RBO-136 weighs approximately 3,300 kg with overall dimensions of 106" × 77" × 98". Every RBO-136 ships with on-site installation, commissioning, and operator training included, backed by RotoBake's 10-year spare-parts guarantee. RotoBake has manufactured bakery machinery in New Delhi since 1964 and exports to bakeries across the Middle East, South Asia, and Africa.
Technical Specifications
| Tray Capacity | 136 Trays (13" × 18") |
| Baking Area | 45,016 sq.in |
| Bread Production | 343 pcs per 25 min |
| Cookie Capacity | 100 kg/hr |
| Temperature Range | Ambient – 350°C |
| Fuel Options | Diesel / Gas |
| Diesel Consumption | 5 L/hr |
| Gas Consumption | 4.5 kg/hr |
| Machine Weight | 3,300 kg |
| Overall Dimensions | 106" × 77" × 98" |
| Rusk Capacity | 1,400 kg per 24 hrs |
Related models: RBO-120 rotary rack oven (120 trays), RBO-172 rotary rack oven (172 trays) and RBO-88 rotary rack oven (88 trays). Or compare all rotary rack oven models.
